产品特性
01
这可以应用于 C&I 市场以及大型微电网市场。
02
Support multiple operation modes such as PQ/VF/VSG.
03
Flexible voltage level support.
04
Result in high efficiency with low consumption.
05
Strong ability to deal with power grid faults.
06
High protection level to adapt to more application scenarios.
产品拓扑
| Model | INPBESS-1250 | |
| Power Configuration Parameters | ||
| BESS rated DC discharge ratio | 0.5P | |
| BESS DC rated power(kW) | 1250kW | |
| Rated power of AC output (kW) | 1250kW | |
| Rated power of AC input (kW) | 1250kW | |
| DC Side Parameters | ||
| Cell type and capacity(Ah) | LFP628Ah | |
| Rated capacity (kWh) | 2508kWh | |
| Battery configuration | 1P52S×8×3 | |
| Voltage range (V) | DC1165~1498V | |
| AC Side Parameters | ||
| AC rated woltage (V) | 690V(-10%~10%) (690V/400V Transformer as an option) | |
| Rated frequency(Hz) | 50Hz(±5Hz) | |
| Rated output current (A) | 1046A | |
| Rated input current(A) | 1046A | |
| Access method | Three-phase three-wire With transformer three-phase four-wire as an option) | |
| On-grid/off-grid function | Support | |
| System Parameters | ||
| Operation temperature range(℃) | -35℃~60℃(>45℃ derating) | |
| Operation humidity range(%) | 0～95%RH | |
| Fire Protection System | (1)Smoke,temperature,CO three-in-one detection, (2)Exhaust explosion-proof valve,(3)Aerosol fire extinguisher,(4)Water spray fire protection. | |
| Thermal Management System | DC liquid cooling,AC air cooling | |
| Protection grade | IP54 | |
| Anti-corosion grade | C4/C5(optional) | |
| Altitude | 3000m(Full load) | 2000m(Full load) |
| Communication interface | RS485、CAN、Ethernet,4G | |
| Dimensions(W*D*H) | 6058×2438×2896mm | |
| Weight (t) | about 40t | |
