产品特性
01
支持多种通信接口，包括 RS485/Ethernet/CAN, 支持 Modbus/RTU、Modbus/TCP、IEC104、IEC61850、CAN2.0B 等通信协议。
02
Modular design of core components for easy maintenance.
03
Support PQ/VF/SG operation mode.
04
The integrated 20-ft solution is more suitable for transportation.
05
Support high/low voltage ride-through, zero voltage ride-through, and continuous fault ride-through.
06
IP65 high protection level, C5 anti-corrosion, suitable for various outdoor complex-environment applications.
07
Three-level design, maximum efficiency up to 99%.
08
Fast power dispatch response, PCS power response time <20 ms.
技术参数
| 模型 | INPPCS-1250 |
| 直流侧参数 | |
| 额定功率 | 1250kW |
| DC Voltage Range | 1000Vdc~1520Vdc |
| Rated DC current | 1250A |
| AC Side Parameters | |
| Rated Power | 1250kW |
| Rated AC Voltage | 690Vac(-10%~10%) |
| Rated AC Current | 1046A |
| Grid Frequency Range | 50Hz(±5Hz) |
| THDI | ≤3%(Full load) |
| THDU | ≤3%(Linear load) |
| AC PF | -1~1 |
| General Parameters | |
| Protection | IP65 |
| Altitude | 3000m(Full load) |
| Temperature | -35℃~60℃(>45℃ derating) |
| Humidity | ≤95%(No condensation) |
| Cooling method | Forced air cooling |
| Maximum Efficiency | ≥99% |
| Dimension | W800*D1400*H2250 |
| Weight | 1200kg |
| BMS Communication | CAN/RS485 |
| EMS Communication | Ethernet/RS485 |
| Certification | EN/IEC 61000-6-2/4 EN/IEC 62477-1 Grid Code such as EN 50549/VDE 4110/G99 etc. |
